4 Zone Asenware Conventional Fire Alarm Panel
KSh16,500.00
4 Zone Asenware Conventional Fire Panel Features:-
Item – 4 Zone Panel
Model No. – AW-CFP2166-4
Mains Supply Voltage – 110VAC or 240VAC
Internal Power Supply – 27.2VDC
Total Output Current – 3A @ 240VAC
Batteries (Default Conf) – 12V 2AH * 2 = 24VDC in Total
End of Line Device – 6.8kOhms. 5% tolerance, 0.25W (color code – blue,grey,red,gold)
Dimensions(mm) – 395*502*124mm
Weight – 7KG
Weight(with batteries) – 9.6KG
4 Zone Asenware Conventional Fire Alarm Panel; AW-CFP2166 series conventional fire alarm panel is designed based on EN54 part 2＆4 standard. And it is the central part of the conventional fire alarm system, designed for applications requiring smoke detectors, bell, manual pull stations, and sprinkler supervision. Each zone can be disabled by a button. The basic unit offers 1 to 8 zones of initiation, up to 16 zones for larger applications.
Specifications:
1. AW-CFP2166-4 conventional fire alarm panel is designed based on EN54 part 2 & 4 standard.
2. Adopted modularized design, flexible extendable capacity.
3. Two-level control mode by a lock
4.27VDC power supply output.
5. FIRE PROTECTION, FIRE ROUTING, and FAULT signal output, the output can be configured to dry relay type or wet sources type.
